Powerstroke 7.3L Turbo 360° Thrust System Severe Duty Rebuild Kit (1994 - 2003)
Year: 1994 - 2003
Application: Ford Powerstroke Diesel
Engine Displacement: 7.3 Liter
(Part Number: 817-1004-002F)
The most complete turbo rebuild kit currently available on the market for Ford Powerstroke 7.3 liter turbos.
360 degree thrust system
The advantage of a 360 degree thrust bearing is that it has a full circle of lubrication, and an updated pad strategy to better disperse oil where it's needed. Most of the performance diesel turbos are run with this kind of set up for durability and longevity. Along with the improved journal bearing design, you will get a much better oil flow versus the conventional 270 degree thrust bearing.
Upgraded step gap seal ring set
Would you like to minimize the possibility of oil leak in your turbo? This upgraded stepped gap seal rings provide a superior seal over the stock style seal rings. They keep your wheels clean, free of deposits and crud caused by oil leaking through the seals.
Improved design journal bearings
These improved design journal bearings use a countersunk oil port, thus draw more oil as they rotate. This bearing design will provide much better oil lubrication to other internal parts, such as the turbine shaft.
